General Specification
♦ Material:
Frame And Impeller:Thermal Plastic UL 94V-0
♦ Lead Wires:UL Type
RED Wire Positive(+)
Black Wire Negative(-)
♦ Insulation Resistance:10MΩ Or Over With a DC250V Megger
♦ Dielectric Withstand Voltage:AC500V 1S
♦ Allowable Ambient Temperature Range:
-10℃～+70℃(Operation)
-40℃～+70℃(Storage)
|
型号 |
轴承类型 |
电压 |
电压范围 |
电流 |
转数 |
风量 |
风压 |
噪音 |
重量 |
|
VDC |
VDC |
A |
RPM |
CFM |
mmH2O |
dBA |
G |
||
|
ADH2510S |
Sleeve |
12 |
10.8～13.2 |
0.12 |
13000 |
2.90 |
6.93 |
30.78 |
6 |
|
ADM2510S |
0.10 |
10000 |
2.22 |
5.01 |
24.11 |
6 |
|||
|
ADL2510S |
0.08 |
7000 |
1.53 |
2.40 |
18.97 |
6 |
|||
|
ADH2510B |
Ball |
0.12 |
13000 |
2.90 |
6.93 |
30.78 |
6 |
||
|
ADM2510B |
0.10 |
10000 |
2.22 |
5.01 |
24.11 |
6 |
|||
|
ADL2510B |
0.08 |
7000 |
1.53 |
2.40 |
18.97 |
6 |
Notes:1.Specifications Subject To Change Without Notice;
2.Design and provide products according to customer requirements.
