General Specification
♦ Material:
Frame And Impeller:Thermal Plastic UL 94V-0
♦ Lead Wires:UL Type
RED Wire Positive(+)
Black Wire Negative(-)
♦ Insulation Resistance:10MΩ Or Over With a DC250V Megger
♦ Dielectric Withstand Voltage:AC500V 1S
♦ Allowable Ambient Temperature Range:
-10℃～+70℃(Operation)
-40℃～+70℃(Storage)
|
型号 |
轴承类型 |
电压 |
电压范围 |
电流 |
转数 |
风量 |
风压 |
噪音 |
重量 |
|
VDC |
VDC |
A |
RPM |
CFM |
mmH2O |
dBA |
G |
||
|
ADH5025S |
Sleeve |
12 |
10.8～13.2 |
0.15 |
6000 |
17.83 |
5.84 |
37.00 |
35 |
|
ADM5025S |
0.11 |
5000 |
14.85 |
4.86 |
30.83 |
||||
|
ADL5025S |
0.08 |
4000 |
11.88 |
3.89 |
24.66 |
||||
|
ADH5025B |
Ball |
0.15 |
6000 |
17.83 |
5.84 |
37.00 |
|||
|
ADM5025B |
0.11 |
5000 |
14.85 |
4.86 |
30.83 |
||||
|
ADL5025B |
0.08 |
4000 |
11.88 |
3.89 |
24.66 |
||||
|
ADH5025S |
Sleeve |
24 |
21.6～26.4 |
0.10 |
6000 |
17.83 |
5.84 |
37.00 |
|
|
ADM5025S |
0.08 |
5000 |
14.85 |
4.86 |
30.83 |
||||
|
ADL5025S |
0.06 |
4000 |
11.88 |
3.89 |
24.66 |
||||
|
ADH5025B |
Ball |
0.10 |
6000 |
17.83 |
5.84 |
37.00 |
|||
|
ADM5025B |
0.08 |
5000 |
14.85 |
4.86 |
30.83 |
||||
|
ADL5025B |
0.06 |
4000 |
11.88 |
3.89 |
24.66 |
Notes:1.Specifications Subject To Change Without Notice;
2.Design and provide products according to customer requirements.
