General Specification
♦ Material:
Impeller: PBT UL 94V-0 Reinforced Plastic
Frame :Aluminium Alloy
♦ Lead Wires:UL Type
RED Wire Positive(+)
Black Wire Negative(-)
♦ Insulation Resistance:10MΩ Or Over With a DC250V Megger
♦ Dielectric Withstand Voltage:AC500V 1S
♦ Allowable Ambient Temperature Range:
-10℃～+70℃(Operation)
-40℃～+70℃(Storage)
| 型号 Model |
轴承类型 Bearing Type |
电压 Rated Voltage |
电压范围 Operation Voltage |
电流 Current |
转数 Speed |
风量 Air Flow |
风压 Static Pressure |
噪音 Noise Level |
重量 Weight |
| VDC | VDC | A | RPM | CFM | mmH2O | dBA | G | ||
| ADD20060B | Ball | 24 | 21.6～26.4 | 2.00 | 2800 | 595.00 | 65.00 | 74.40 | 1520 |
| ADH20060B | 1.50 | 2500 | 531.00 | 58.20 | 67.00 | ||||
| ADM20060B | 1.00 | 2200 | 467.00 | 51.50 | 55.80 | ||||
| ADL20060B | 0.70 | 2000 | 425.00 | 46.40 | 46.50 | ||||
| ADD20060B | 48 | 43.2～52.8 | 1.10 | 2800 | 595.00 | 65.00 | 74.40 | ||
| ADH20060B | 0.80 | 2500 | 531.00 | 58.20 | 67.00 | ||||
| ADM20060B | 0.60 | 2200 | 467.00 | 51.50 | 55.80 | ||||
| ADL20060B | 0.40 | 2000 | 425.00 | 46.40 | 46.50 |
Notes:1.Specifications Subject To Change Without Notice;
2.Design and provide products according to customer requirements.
