General specification
♦ Material:
Impeller:PBT UL 94V-0 Reinforced Plastic
Frame:Aluminium Alloy
♦ Lead Wires:UL Type
♦ Motor Protection:Impredance Protect
♦ Insulation Resistance:10MΩ Or Over With a DC500V Megger
♦ Dielectric Withstand Voltage:AC1500V 3S
♦ Allowable Ambient Temperature Range:
-10℃～+70℃(Operation)
-40℃～+70℃(Storage)
| 型号 Model |
轴承类型 Bearing Type |
电压 Rated Voltage |
频率 Fre-quency |
电流 Current |
功率 Power |
转数 Speed |
噪音 Noise Level |
风量 Air Flow |
风压 Static Pressure |
重量 Weight |
|
| VAC | Hz | A | W | RPM | dBA | m3/min | CFM | mmH2O | G | ||
| AAH1751S | Sleeve | 115 | 50/60 | 0.50/0.45 | 37/36 | 2700/3100 | 45/50 | 5.37/6.65 | 190/235 | 16.00/17.78 | 908 |
| AAH1751B | Ball | ||||||||||
| AAH1751S | Sleeve | 220～240 | 0.22/0.21 | 34/33 | |||||||
| AAH1751B | Ball | ||||||||||
| AAH1751S | Sleeve | 380 | 50 | 0.11 | 34 | 2700 | 45 | 5.37 | 190 | 16 | |
| AAH1751B | Ball | ||||||||||
Notes:1.Specifications Subject To Change Without Notice;
2.Design and provide products according to customer requirements.
