General Specification
♦ Material:
Frame And Impeller:Thermal Plastic UL 94V-0
♦ Lead Wires:UL Type
RED Wire Positive(+)
Black Wire Negative(-)
♦ Insulation Resistance:10MΩ Or Over With a DC250V Megger
♦ Dielectric Withstand Voltage:AC500V 1S
♦ Allowable Ambient Temperature Range:
-10℃~+70℃(Operation)
-40℃~+70℃(Storage)
型号 Model |
轴承类型 Bearing Type |
电压 Rated Voltage |
电压范围 Operation Voltage |
电流 Current |
转数 Speed |
风量 Air Flow |
风压 Static Pressure |
噪音 Noise Level |
重量 Weight |
VDC | VDC | A | RPM | CFM | mmH2O | dBA | G | ||
ADH8020S | Sleeve | 12 | 10.8~13.2 | 0.20 | 3200 | 33.95 | 3.55 | 30.67 | 69 |
ADM8020S | 0.15 | 2800 | 29.29 | 2.70 | 26.95 | ||||
ADL8020S | 0.10 | 2400 | 25.15 | 2.03 | 23.62 | ||||
ADH8020B | Ball | 0.20 | 3200 | 33.95 | 3.55 | 30.67 | |||
ADM8020B | 0.15 | 2800 | 29.29 | 2.70 | 26.95 | ||||
ADL8020B | 0.10 | 2400 | 25.15 | 2.03 | 23.62 | ||||
ADH8020S | Sleeve | 24 | 21.6~26.4 | 0.11 | 3200 | 33.95 | 3.55 | 30.67 | |
ADM8020S | 0.09 | 2800 | 29.29 | 2.70 | 26.95 | ||||
ADL8020S | 0.07 | 2400 | 25.15 | 2.03 | 23.62 | ||||
ADH8020B | Ball | 0.11 | 3200 | 33.95 | 3.55 | 30.67 | |||
ADM8020B | 0.09 | 2800 | 29.29 | 2.70 | 26.95 | ||||
ADL8020B | 0.07 | 2400 | 25.15 | 2.03 | 23.62 |
Notes:1.Specifications Subject To Change Without Notice;
2.Design and provide products according to customer requirements.
