General Specification
♦ Material:
Frame And Impeller:Thermal Plastic UL 94V-0
♦ Lead Wires:UL Type
RED Wire Positive(+)
Black Wire Negative(-)
♦ Insulation Resistance:10MΩ Or Over With a DC250V Megger
♦ Dielectric Withstand Voltage:AC500V 1S
♦ Allowable Ambient Temperature Range:
-10℃～+70℃(Operation)
-40℃～+70℃(Storage)
| 型号 Model |
轴承类型 Bearing Type |
电压 Rated Voltage |
电压范围 Operation Voltage |
电流 Current |
转数 Speed |
风量 Air Flow |
风压 Static Pressure |
噪音 Noise Level |
重量 Weight |
| VDC | VDC | A | RPM | CFM | mmH2O | dBA | G | ||
| ADH5010S | Sleeve | 5 | 4.5～5.5 | 0.25 | 5000 | 10.43 | 2.52 | 28.44 | 20 |
| ADM5010S | 0.20 | 4500 | 9.42 | 2.27 | 26.09 | ||||
| ADL5010S | 0.15 | 3500 | 7.30 | 1.77 | 20.82 | ||||
| ADH5010B | Ball | 0.25 | 5000 | 10.43 | 2.52 | 28.44 | |||
| ADM5010B | 0.20 | 4500 | 9.42 | 2.27 | 26.09 | ||||
| ADL5010B | 0.15 | 3500 | 7.30 | 1.77 | 20.82 | ||||
| ADH5010S | Sleeve | 12 | 10.8～13.2 | 0.16 | 5000 | 10.43 | 2.52 | 28.44 | |
| ADM5010S | 0.12 | 4500 | 9.42 | 2.27 | 26.09 | ||||
| ADL5010S | 0.08 | 3500 | 7.30 | 1.77 | 20.82 | ||||
| ADH5010B | Ball | 0.16 | 5000 | 10.43 | 2.52 | 28.44 | |||
| ADM5010B | 0.12 | 4500 | 9.42 | 2.27 | 26.09 | ||||
| ADL5010B | 0.08 | 3500 | 7.30 | 1.77 | 20.82 |
Notes:1.Specifications Subject To Change Without Notice;
2.Design and provide products according to customer requirements.
