General Specification
♦ Material:
Frame And Impeller:Thermal Plastic UL 94V-0
♦ Lead Wires:UL Type
RED Wire Positive(+)
Black Wire Negative(-)
♦ Insulation Resistance:10MΩ Or Over With a DC250V Megger
♦ Dielectric Withstand Voltage:AC500V 1S
♦ Allowable Ambient Temperature Range:
-10℃～+70℃(Operation)
-40℃～+70℃(Storage)
| 型号 Model |
轴承类型 Bearing Type |
电压 Rated Voltage |
电压范围 Operation Voltage |
电流 Current |
转数 Speed |
风量 Air Flow |
风压 Static Pressure |
噪音 Noise Level |
重量 Weight |
| VDC | VDC | A | RPM | CFM | mmH2O | dBA | G | ||
| ADH3510S | Sleeve | 5 | 4.5～5.5 | 0.23 | 9000 | 6.30 | 3.68 | 32.37 | 9 |
| ADM3510S | 0.22 | 7000 | 5.06 | 2.44 | 25.88 | ||||
| ADL3510S | 0.13 | 5000 | 3.51 | 1.28 | 20.26 | ||||
| ADH3510B | Ball | 0.23 | 9000 | 6.30 | 3.68 | 32.37 | |||
| ADM3510B | 0.22 | 7000 | 5.06 | 2.44 | 25.88 | ||||
| ADL3510B | 0.13 | 5000 | 3.51 | 1.28 | 20.26 | ||||
| ADH3510S | Sleeve | 12 | 10.8～13.2 | 0.15 | 9000 | 6.30 | 3.68 | 32.37 | |
| ADM3510S | 0.10 | 7000 | 5.06 | 2.44 | 25.88 | ||||
| ADL3510S | 0.08 | 5000 | 3.51 | 1.28 | 20.26 | ||||
| ADH3510B | Ball | 0.15 | 9000 | 6.30 | 3.68 | 32.37 | |||
| ADM3510B | 0.10 | 7000 | 5.06 | 2.44 | 25.88 | ||||
| ADL3510B | 0.08 | 5000 | 3.51 | 1.28 | 20.26 |
Notes:1.Specifications Subject To Change Without Notice;
2.Design and provide products according to customer requirements.
