General Specification
♦ Material:
Impeller:Galvanized Steel
Scroll Housing:Black Paint
♦ Weight:1.8KG
♦ Bearing Type:Ball
♦ Class B,Electric Protected
♦ G2.5 Balancing
♦ IP44 Protection Depending On Installation
And Position As Per EN60034-5
| 型号 Model |
轴承类型 Bearing Type |
电压 Rated Voltage |
频率 Fre-quency |
电流 Current |
功率 Power |
转数 Speed |
噪音 Noise Level |
风量 Maximun Air Flow |
风压 Static Pressure |
重量 Weight |
|
| VAC | Hz | A | W | RPM | dBA | m3/h | CFM | mmH2O | G | ||
| AEH1615B | Ball | 115/230 | 50/60 | 0.50 | 70 | 1400 | 59 | 414 | 243.90 | 44.41 | 1800 |
| AEM1615B | 0.20 | 30 | 1050 | 44 | 310 | 182.93 | 33.31 | ||||
Notes:1.Specifications Subject To Change Without Notice;
2.Design and provide products according to customer requirements.
