General Specification
♦ Material:
Frame And Impeller:Thermal Plastic UL 94V-0
♦ Lead Wires:UL Type
RED Wire Positive(+)
Black Wire Negative(-)
♦ Operation Temperature:-10℃～+70℃
35%～85%RH
♦ Storage Temperature:-40℃～+70℃
35%～85%RH
| 型号 Model |
轴承类型 Bearing Type |
电压 Rated Voltage |
频率 Fre-quency |
电流 Current |
功率 Power |
转数 Speed |
噪音 Noise Level |
风量 Maximun Air Flow |
风压 Static Pressure |
重量 Weight |
|
| VAC | Hz | A | W | RPM | dBA | m3/h | CFM | mmH2O | G | ||
| AEH1238S | Sleeve | 115/230 | 50/60 | 0.09 | 6.0 | 3000 | 45 | 197.5 | 116.3 | 8.0 | 270 |
| AEM1238S | 0.07 | 5.5 | 2500 | 40 | 168.4 | 99.2 | 5.6 | ||||
| AEL1238S | 0.05 | 5.0 | 2000 | 34 | 131.4 | 77.4 | 3.3 | ||||
| AEH1238B | Ball | 115/230 | 50/60 | 0.09 | 6.0 | 3000 | 45 | 197.5 | 116.3 | 8.0 | |
| AEM1238B | 0.07 | 5.5 | 2500 | 40 | 168.4 | 99.2 | 5.6 | ||||
| AEL1238B | 0.05 | 5.0 | 2000 | 34 | 131.4 | 77.4 | 3.3 | ||||
Notes:1.Specifications Subject To Change Without Notice;
2.Design and provide products according to customer requirements.
