General Specification
♦ Material:
Frame And Impeller:Thermal Plastic UL 94V-0
♦ Lead Wires:UL Type
RED Wire Positive(+)
Black Wire Negative(-)
♦ Insulation Resistance:10MΩ Or Over With a DC250V Megger
♦ Dielectric Withstand Voltage:AC500V 1S
♦ Allowable Ambient Temperature Range:
-10℃～+70℃(Operation)
-40℃～+70℃(Storage)
| 型号 Model |
轴承类型 Bearing Type |
电压 Rated Voltage |
电压范围 Operation Voltage |
电流 Current |
转数 Speed |
风量 Air Flow |
风压 Static Pressure |
噪音 Noise Level |
重量 Weight |
| VDC | VDC | A | RPM | CFM | mmH2O | dBA | G | ||
| ADH2510S | Sleeve | 5 | 4.5～5.5 | 0.20 | 13000 | 2.90 | 6.93 | 30.78 | 6 |
| ADM2510S | 0.16 | 10000 | 2.22 | 5.01 | 24.11 | ||||
| ADL2510S | 0.14 | 7000 | 1.53 | 2.40 | 18.97 | ||||
| ADH2510B | Ball | 0.20 | 13000 | 2.90 | 6.93 | 30.78 | |||
| ADM2510B | 0.16 | 10000 | 2.22 | 5.01 | 24.11 | ||||
| ADL2510B | 0.14 | 7000 | 1.53 | 2.40 | 18.97 | ||||
| ADH2510S | Sleeve | 12 | 10.8～13.2 | 0.12 | 13000 | 2.90 | 6.93 | 30.78 | |
| ADM2510S | 0.10 | 10000 | 2.22 | 5.01 | 24.11 | ||||
| ADL2510S | 0.08 | 7000 | 1.53 | 2.40 | 18.97 | ||||
| ADH2510B | Ball | 0.12 | 13000 | 2.90 | 6.93 | 30.78 | |||
| ADM2510B | 0.10 | 10000 | 2.22 | 5.01 | 24.11 | ||||
| ADL2510B | 0.08 | 7000 | 1.53 | 2.40 | 18.97 |
Notes:1.Specifications Subject To Change Without Notice;
2.Design and provide products according to customer requirements.
