General Specification
♦ Material:
Frame And Impeller:Thermal Plastic UL 94V-0
♦ Lead Wires:UL Type
RED Wire Positive(+)
Black Wire Negative(-)
♦ Insulation Resistance:10MΩ Or Over With a DC250V Megger
♦ Dielectric Withstand Voltage:AC500V 1S
♦ Allowable Ambient Temperature Range:
-10℃～+70℃(Operation)
-40℃～+70℃(Storage)
| 型号 Model |
轴承类型 Bearing Type |
电压 Rated Voltage |
电压范围 Operation Voltage |
电流 Current |
转数 Speed |
风量 Air Flow |
风压 Static Pressure |
噪音 Noise Level |
重量 Weight |
| VDC | VDC | A | RPM | CFM | mmH2O | dBA | G | ||
| ADH6020S | Sleeve | 12 | 10.8～13.2 | 0.15 | 4000 | 20.28 | 3.65 | 29.04 | 49 |
| ADM6020S | 0.10 | 3300 | 16.50 | 2.50 | 23.85 | ||||
| ADL6020S | 0.07 | 2500 | 12.31 | 1.45 | 21.35 | ||||
| ADH6020B | Ball | 0.15 | 4000 | 20.28 | 3.65 | 29.04 | |||
| ADM6020B | 0.10 | 3300 | 16.50 | 2.50 | 23.85 | ||||
| ADL6020B | 0.07 | 2500 | 12.31 | 1.45 | 21.35 | ||||
| ADH6020S | Sleeve | 24 | 21.6～26.4 | 0.12 | 4000 | 20.28 | 3.65 | 29.04 | |
| ADM6020S | 0.08 | 3300 | 16.50 | 2.50 | 23.85 | ||||
| ADL6020S | 0.05 | 2500 | 12.31 | 1.45 | 21.35 | ||||
| ADH6020B | Ball | 0.12 | 4000 | 20.28 | 3.65 | 29.04 | |||
| ADM6020B | 0.08 | 3300 | 16.50 | 2.50 | 23.85 | ||||
| ADL6020B | 0.05 | 2500 | 12.31 | 1.45 | 21.35 |
Notes:1.Specifications Subject To Change Without Notice;
2.Design and provide products according to customer requirements.
