General Specification
♦ Material:
Frame And Impeller:Thermal Plastic UL 94V-0
♦ Lead Wires:UL Type
RED Wire Positive(+)
Black Wire Negative(-)
♦ Operation Temperature:-10℃～+70℃
35%～85%RH
♦ Storage Temperature:-40℃～+70℃
35%～85%RH
| 型号 Model |
轴承类型 Bearing Type |
电压 Rated Voltage |
频率 Fre-quency |
电流 Current |
功率 Power |
转数 Speed |
噪音 Noise Level |
风量 Maximun Air Flow |
风压 Static Pressure |
重量 Weight |
|
| VAC | Hz | A | W | RPM | dBA | m3/h | CFM | mmH2O | G | ||
| AEH8038B | Ball | 220 | 50 | 0.20 | 4.0 | 3000 | 37 | 68.1 | 40.1 | 5.3 | 155 |
| AEM8038B | 0.18 | 3.5 | 2500 | 32 | 56.5 | 33.3 | 3.7 | ||||
| AEL8038B | 0.16 | 3.0 | 2000 | 26 | 44.3 | 26.1 | 2.4 | ||||
Notes:1.Specifications Subject To Change Without Notice;
2.Design and provide products according to customer requirements.
