General specification
♦ Material:
Frame And Impeller:Thermal Plastic UL 94-0
♦ Lead Wires:UL Type
RED Wire Positive(+)
Black Wire Negative(-)
♦ Operation Temperature:-10℃～+70℃
35%～85%RH
♦ Storage Temperature:-40℃～+70℃
35%～85%RH
| 型号 Model |
轴承类型 Bearing Type |
电压 Rated Voltage |
频率 Fre-quency |
电流 Current |
功率 Power |
转数 Speed |
噪音 Noise Level |
风量 Air Flow |
风压 Static Pressure |
重量 Weight |
|
| VAC | Hz | A | W | RPM | dBA | m3/min | CFM | mmH2O | G | ||
| AAH9238B | Ball | 220 | 50 | 0.25 | 5.0 | 3000 | 36 | 76.7 | 45.2 | 5.4 | 300 |
| AAM9238B | 0.20 | 4.0 | 2500 | 30 | 64.0 | 37.7 | 3.7 | ||||
Notes:1.Specifications Subject To Change Without Notice;
2.Design and provide products according to customer requirements.
