General specification
♦ Material:
Impeller:PBT UL 94V-0 Reinforced Plastic
Frame:Aluminium Alloy
♦ Lead Wires:UL Type
♦ Motor Protection:Impredance Protect
♦ Insulation Resistance:10MΩ Or Over With a DC500V Megger
♦ Dielectric Withstand Voltage:AC1500V 3S
♦ Allowable Ambient Temperature Range:
-10℃～+70℃(Operation)
-40℃～+70℃(Storage)
| 型号 Model |
轴承类型 Bearing Type |
电压 Rated Voltage |
频率 Fre-quency |
电流 Current |
功率 Power |
转数 Speed |
噪音 Noise Level |
风量 Air Flow |
风压 Static Pressure |
重量 Weight |
|
| VAC | Hz | A | W | RPM | dBA | m3/min | CFM | mmH2O | G | ||
| AAH8025S | Sleeve | 115 | 50/60 | 0.12/0.10 | 12/11 | 2550/2900 | 29/33 | 0.51/0.62 | 18/22 | 3.30/4.83 | 260 |
| AAH8025B | Ball | ||||||||||
| AAH8025S | Sleeve | 220～240 | 0.07/0.06 | 14/13.5 | 2500/2900 | ||||||
| AAH8025B | Ball | ||||||||||
Notes:1.Specifications Subject To Change Without Notice;
2.Design and provide products according to customer requirements.
