General Specification
♦ Material:
Frame And Impeller:Thermal Plastic UL 94V-0
♦ Lead Wires:UL Type
RED Wire Positive(+)
Black Wire Negative(-)
♦ Insulation Resistance:10MΩ Or Over With a DC250V Megger
♦ Dielectric Withstand Voltage:AC500V 1S
♦ Allowable Ambient Temperature Range:
-10℃～+70℃(Operation)
-40℃～+70℃(Storage)
| 型号 Model |
轴承类型 Bearing Type |
电压 Rated Voltage |
电压范围 Operation Voltage |
电流 Current |
转数 Speed |
风量 Air Flow |
风压 Static Pressure |
噪音 Noise Level |
重量 Weight |
| VDC | VDC | A | RPM | CFM | mmH2O | dBA | G | ||
| ADH4015S | Sleeve | 5 | 4.5～5.5 | 0.27 | 8000 | 10.56 | 7.29 | 36.90 | 21 |
| ADM4015S | 0.22 | 7000 | 9.36 | 5.69 | 33.20 | ||||
| ADL4015S | 0.16 | 6000 | 7.95 | 4.14 | 29.30 | ||||
| ADH4015B | Ball | 0.27 | 8000 | 10.56 | 7.29 | 36.90 | |||
| ADM4015B | 0.22 | 7000 | 9.36 | 5.69 | 33.20 | ||||
| ADL4015B | 0.16 | 6000 | 7.95 | 4.14 | 29.30 | ||||
| ADH4015S | Sleeve | 12 | 10.8～13.2 | 0.13 | 8000 | 10.56 | 7.29 | 36.90 | |
| ADM4015S | 0.10 | 7000 | 9.36 | 5.69 | 33.20 | ||||
| ADL4015S | 0.08 | 6000 | 7.95 | 4.14 | 29.30 | ||||
| ADH4015B | Ball | 0.13 | 8000 | 10.56 | 7.29 | 36.90 | |||
| ADM4015B | 0.10 | 7000 | 9.36 | 5.69 | 33.20 | ||||
| ADL4015B | 0.08 | 6000 | 7.95 | 4.14 | 29.30 |
Notes:1.Specifications Subject To Change Without Notice;
2.Design and provide products according to customer requirements.
