General Specification
♦ Material:
Frame And Impeller:Thermal Plastic UL 94V-0
♦ Lead Wires:UL Type
RED Wire Positive(+)
Black Wire Negative(-)
♦ Insulation Resistance:10MΩ Or Over With a DC250V Megger
♦ Dielectric Withstand Voltage:AC500V 1S
♦ Allowable Ambient Temperature Range:
-10℃~+70℃(Operation)
-40℃~+70℃(Storage)
型号 Model |
轴承类型 Bearing Type |
电压 Rated Voltage |
电压范围 Operation Voltage |
电流 Current |
转数 Speed |
风量 Air Flow |
风压 Static Pressure |
噪音 Noise Level |
重量 Weight |
VDC | VDC | A | RPM | CFM | mmH2O | dBA | G | ||
ADH2006S | Sleeve | 5 | 4.5~5.5 | 0.22 | 15000 | 1.41 | 5.22 | 33.65 | 4 |
ADM2006S | 0.17 | 12000 | 1.02 | 3.69 | 26.87 | ||||
ADL2006S | 0.12 | 9000 | 0.77 | 2.02 | 20.34 |
Notes:1.Specifications Subject To Change Without Notice;
2.Design and provide products according to customer requirements.
